| Platform Technology: | Intel vPro Platform |
| Type (General): | Personal computer |
| Type (Hard Drive): | SSD - M.2 2280 |
| Type (Storage Controller): | 1 x SATA/NVMe |
| Type (Optical Storage): | No optical drive |
| Product Form Factor: | Mini desktop |
| Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
| Localisation: | Language: English / region: Europe |
| Bundled with: | Microsoft Team Rooms |
| CPU: | Intel Core i7 (13th Gen) 13700T |
| Clock Speed: | 1.4 GHz (P-core) / 1 GHz (E-core) |
| Max Turbo Speed: | 4.9 GHz (P-core) / 3.6 GHz (E-core) |
| Number of Cores: | 16-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| L2 cache: | 24 MB |
| CPU Upgradability: | Upgradable |
| Processor Main Features: | Intel Turbo Boost Technology |
| Chipset Type: | Intel Q670 |
| Installed Size (Cache Memory): | L3 Cache - 30 MB |
| Installed Size (RAM): | 16 GB (installed) / 64 GB (max) |
| Cache Per Processor: | 30 MB |
| Technology: | DDR5 SDRAM |
| Effective Memory Speed: | 2400 MHz |
| Rated Memory Speed: | 2400 MHz |
| Form Factor: | SO-DIMM 262-pin |
| Slots: | 2 (Total) / 0 (empty) |
| Configuration Features: | 2 x 8 GB |
| Capacity: | 1 x 256 GB |
| Interface Type: | PCI Express |
| Features (Hard Drive): | NVM Express (NVMe) |
| Features (Networking): | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), MU-MIMO Support, PXE 2.1 support, dual stream (2x2) |
| Controller Interface Type: | SATA-600 / NVMe |
| Monitor Type: | None. |
| Graphics Processor: | Intel UHD Graphics 770 Dynamic Video Memory Technology |
| Video Interfaces: | HDMI, DisplayPort |
| HDCP Compatible: | Yes |
| Sound Output Mode: | Stereo |
| Max Sampling Rate: | 192 kHz |
| Compliant Standards (Audio Output): | High Definition Audio |
| Compliant Standards (Networking): | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.11d, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11e, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v |
| Interface (Bus) Type: | PCI Express Mini Card (M.2) |
| Ethernet Controller: | Intel I219-LM |
| Wireless LAN Supported: | Yes |
| Wireless NIC: | Intel Wi-Fi 6E AX 211 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Remote Management Protocol: | SNMP 2 |
| Bays: | 1 (total) / 1 (free) x internal 2.5" |
| Theft/Intrusion Protection: | Security lock slot (cable lock sold separately), retractable padlock loop |
| Security Slot Type: | Kensington security slot |
| Device Type: | Power adapter |
| Voltage Required: | AC 90-264 V (50/60 Hz) |
| Power Provided: | 150 Watt |
| Efficiency: | 89% (230VAC), 88% (115VAC) |
| Power Factor Correction: | Yes (active) |
| OS Provided: | Windows 11 IoT Enterprise English |
| Software: | HP Image Assistant (free download), HP Sure Sense, Microsoft Teams Rooms, Poly Lens management software, HP Manageability Integration Kit (free download), HP Sure Start Gen7, HP Console Control, HP Sure Start |
| TCO Certified: | TCO Certified Desktops 9 |
| Service & Support: | Limited warranty - parts and labour - 1 year - on-site |
| Width: | 17.7 cm |
| Depth: | 17.5 cm |
| Height: | 3.4 cm |
| Тегло, kg: | 1.42 |
| Shipping Width: | 49.2 cm |
| Shipping Depth: | 11.4 cm |
| Shipping Height: | 25.1 cm |
| Тегло, kg: | 2.95 |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 10 - 90% RH (non-condensing) |
