| LEGION | Series / Серия - LEGION |
| I7-13 | With Intel i7 13th gen. processor / С процесор Intel i7 13-то поколение |
| 32G | Memory size / Обем на паметта - 32GB |
| RTX5070 | Series / Серия - RTX5070 |
| SSD | SSD / SSD диск |
| WUXGA | Display resolution / Резолюция на екрана - WUXGA (1920 x 1200) |
| IPS | Panel type / Тип на панела(матрицата) - IPS |
| 165HZ | Refresh rate / Честота на опресняване на дисплея - 165Hz |
| BLACK | Color - black / Цвят - черен |
| Model | 83LY00S0BM |
| CPU model | Intel Core™ i7-13650HX, 14C (6P + 8E) / 20T, P-core up to 4.9GHz, E-core up to 3.6GHz, 24MB Intel® Smart Cache |
| Memory size | 32 (2x16GB) |
| Memory type | SODIMM DDR5-4800
Max Memory: Up to 32GB DDR5-4800 offering |
| Graphics | NVIDIA GeForce RTX™ 5070 8GB GDDR7, Boost Clock 2347MHz, TGP 115W, 798 AI TOPS |
| SSD | 1TB |
| Disk specifications | SSD M.2 2242 PCIe® 4.0x4 NVMe® |
| Screen size | 15.3" |
| Screen type | WUXGA IPS 300nits Anti-glare, 100% sRGB, 165Hz, Dolby Vision® |
| Screen resolution | 1920x1200 |
| Interface | 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 95-100W and DisplayPort™ 2.1
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™ 1.4
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Slim tip Power connector
Various docking solutions supported via USB-C® |
| LAN | 100/1000M (RJ-45) |
| Wi-Fi | Wi-Fi® 6, 802.11ax 2x2 |
| Bluetooth | 5.2 |
| Camera | HD 720p with E-shutter |
| Audio | High Definition (HD) Audio, Realtek® ALC3287 codec
Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio
Microphone 2x, Array |
| Keyboard | White Backlit, Bulgarian
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm |
| Expansion slots | Two DDR5 SODIMM slots, dual-channel capable
Two M.2 2280 PCIe® 4.0 x4 slots |
| OS | None |
| Security | Firmware TPM 2.0 Enabled
No Fingerprint Reader
E-shutter |
| Battery | 80Wh |
| Material | PC-ABS + 15% Talc (Top), PC-ABS + 15% Talc (Bottom) |
| Color | Eclipse Black |
| Features | AI Chip: LA1 |
| Power adapter | 245W Slim Tip (3-pin) |
| Weight | Starting at 2.1 kg |
| Dimensions | 344.9 x 255.35 x 22.50-23.99 mm |
