| Model | 13B90018BL |
| Chipset | Intel® SoC Platform |
| CPU model | Intel Core™ i3-1315U, 6C (2P + 4E) / 8T, P-core up to 4.5GHz, E-core up to 3.3GHz, 10MB Intel® Smart Cache |
| Memory size | 8GB |
| Memory type | SODIMM DDR5-5600;
Max Memory: Up to 64GB DDR5-5600 |
| Graphics | Integrated Intel® UHD Graphics |
| SSD | 512GB |
| Disk specifications | SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 |
| Interfaces/Ports | Front Ports:;
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 5V@3A charging;
1x USB-A (USB 10Gbps / USB 3.2 Gen 2), with Always On and 5V@2.1A charging;
1x headphone / microphone combo jack (3.5mm);
Rear Ports:;
2x USB-A (Hi-Speed USB / USB 2.0), one supports Smart Power On;
2x USB-A (USB 10Gbps / USB 3.2 Gen 2);
1x HDMI® 2.1 TMDS;
1x DisplayPort™ 1.4b;
1x Ethernet (GbE RJ-45);
1x Power connector |
| Expansion slots | Two DDR5 SODIMM slots, dual-channel capable;
Three M.2 slots (one for WLAN, two for SSD) |
| LAN | Integrated 100/1000M |
| Wireless | Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 |
| Bluetooth | 5.3 |
| Camera | None |
| Audio | High Definition (HD) Audio, Realtek® ALC256 codec;
Speakers 2Wx1;
No microphone |
| OS | None |
| Power | 65W 89% Adapter |
| Color | Black |
| Security | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified;
No fingerprint reader;
Kensington Security Slot™, 3 x 7 mm;
Chassis Intrusion Switch |
| Certifications | RoHS compliant;
TCO Certified, generation 10;
MIL-STD-810H:2022 military test passed (Solar Radiation 505.7, Salt Fog 509.8, Contamination by fluids 504.3) |
| Accessories | Keyboard: USB, Calliope, Black, Bulgarian;
Mouse: USB Calliope Mouse, Black |
| Weight | Around 1.13 kg |
| Dimensions | Tiny only (without rubber feet) | 179 x 182.9 x 34.5 mm;
Tiny only (with rubber feet) | 179 x 182.9 x 36.5 mm |
