| B760 | Chipset / Чипсет - Intel B760 |
| 2xDDR5 | Number of DDR5 ram slots / Брой слотове за памет DDR5 - 2 |
| 4xSATA3 | Number of SATA3 ports / Брой SATA3 портове за диск - 4 |
| RAID | RAID Supported / Поддържа RAID |
| HDMI | HDMI port / Наличие на HDMI изход |
| DP | Display port / Наличие на Display port изход |
| 2xM2 | 2 x M.2 Slots / 2 броя M.2 слотове |
| 1xPCIEx16 | 1 x PCI Express x16 slot / 1 брой PCI Express x16 слот |
| 1xPCIEx1 | 1 x PCI Express x1 slot / 1 брой PCI Express x1 слот |
| Manufacturer | ASRock |
| Graphics | Intel® Xe Graphics Architecture (Gen 12);1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz;1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz |
| Chipset | Intel® B760 |
| Expansion slots | CPU:;- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode;Chipset:;- 1 x PCIe 3.0 x1 Slots (PCIE2);- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module |
| Storage | Chipset:;- 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode;- 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen3x4 (32 Gb/s) modes;- 4 x SATA3 6.0 Gb/s Connectors;Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| Rear panel I/O | 2 x Antenna Mounting Points;1 x HDMI Port;1 x DisplayPort 1.4;1 x USB 3.2 Gen1 Type-C Port;3 x USB 3.2 Gen1 Type-A Ports;2 x USB 2.0 Ports;1 x RJ-45 LAN Port;HD Audio Jacks: Line in / Front Speaker / Microphone |
| USB | Chipset:;- 1 x USB 3.2 Gen1 Type-C (Rear);- 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front);- 6 x USB 2.0 (2 Rear, 4 Front) |
| Connectors | 1 x SPI TPM Header;1 x Chassis Intrusion and Speaker Header;1 x RGB LED Header;3 x Addressable LED Headers;1 x CPU Fan Connector (4-pin);1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control;2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control);1 x 24 pin ATX Power Connector;1 x 8 pin 12V Power Connector;1 x Front Panel Audio Connector;2 x USB 2.0 Headers (Support 4 USB 2.0 ports);1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) |
| Audio | 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| Lan | 2.5 Gigabit LAN 10/100/1000/2500 Mb/s;Dragon RTL8125BG;Supports Dragon 2.5G LAN Software;Smart Auto Adjust Bandwidth Control;Visual User Friendly UI;Visual Network Usage Statistics;Optimized Default Setting for Game, Browser, and Streaming Modes;User Customized Priority Control |
| BIOS | 128Mb AMI UEFI Legal BIOS with GUI support |
| Form factor | Micro ATX Form Factor: 9.6-in x 8.7-in, 24.4 cm x 22.1 cm |
| OS | Microsoft Windows® 10 64-bit / 11 64-bit |
