| Device Type: | NVR - rack-mountable - 1U |
| Video Channels: | 16 |
| Max Supported Video Channels: | 32 |
| IP Cameras Supported: | 16 |
| Package Content: | Rack mount rails, power cable |
| Software Included (Y): | iDRAC 9 basic license |
| Country Kits: | Argentina, Australia, Brazil, Europe, Japan, Korea, United Kingdom, United States |
| TAA Compliant: | Yes |
| Compliant Standards: | EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZ CISPR 32 Class A, ICES-3(A)/NMB-3(A), VCCI Class A, KS C 9547, KS C 9815, KS C 9835, KS C 9832 Class A, FCC Part 15 B Class A, CNS 15936, IEC 62236-4, KC mark, IEC/EN 62368-1, NOM-019-SCFI-1998, FIPS 140-2 Level 2 |
| Warranty: | 5 years |
| Networked: | Yes |
| Features (Security DVR): | Recording data rate up to 256 Mbps |
| Features (Networking): | Rack mountable (1RU), support RAID 10, support RAID 1, support RAID 0, Trusted Platform Module 2.0 (TPM 2.0) |
| Quantity Installed: | 1 |
| Quantity Supported: | 3 |
| Capacity: | 8 TB |
| Interface: | Serial ATA |
| CPU: | Intel Xeon E |
| Flash Memory: | 16 GB |
| Network Interfaces: | iDRAC, Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Port: | 10/100/1000Base-T x 2 |
| Other Ports: | USB 3.2 x 1, USB 2.0 x2, VGA x 1, serial, iDRAC x 2 |
| Voltage: | 100 - 240 V |
| Frequency: | 50/60 Hz |
| Power Consumption: | 90 Watt |
| Width: | 48.2 cm |
| Depth: | 59.9 cm |
| Height: | 4.3 cm |
| Тегло, kg: | 9.2 |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 5 - 95% RH (non-condensing) |
