| Device Type: | Network surveillance camera |
| Connectivity Technology: | Wired |
| Width: | 11.6 cm |
| Depth: | 16 cm |
| Height: | 6.3 cm |
| Тегло, kg: | 0.77 |
| Type (Camera): | Colour - Day&Night - pan / tilt |
| Type (Image Sensor): | RGB CMOS 1/2.9" |
| Type (Lens Construction): | M12 mount - fixed focal |
| Digital Video Format: | MPEG-4, MJPEG, H.264, AVC, HEVC, H.265 |
| Max Digital Video Resolution: | 1920 x 1080 |
| Motion Detection: | Yes |
| Video Modes: | 1080p |
| Exposure Range: | 2 sec - 1/33500 sec |
| Infrared LEDs: | Yes |
| Still Image Capture Resolution: | 1080p |
| RAM: | 1 GB |
| Flash Memory: | 512 MB |
| Features: | Sharpness control, white balance, progressive scanning, brightness control, contrast control, image mirror, Privacy Mask Function, Electronic Image Stabilizer (EIS), Lightfinder technology, digital PTZ function, password protection, Variable Bitrate (VBR), Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, image overlay, exposure control, Forensic WDR, IP address filtering, exposure zone, guard tour, Corridor mode, ONVIF (Profile T) support, Adaptive Bitrate (ABR), defogging, compression |
| Focal Length: | 6 mm |
| Lens Iris: | F/1.9 fixed iris |
| Horizontal Field of View (degree): | 56 |
| Vertical Field of View (degree): | 30 |
| Range (degree) (Panning): | -20 to +20 |
| Range (degree) (Tilting): | 0 to 15 |
| Network Interface: | Ethernet 10Base-T/100Base-TX |
| Network Protocols: | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, IGMPv2, IGMPv3, CIFS, SRTP, EAP, SFTP, LLDP, USGv6, MQTT |
| Ports: | LAN/power - RJ-45 |
| Supported Memory Cards: | microSD Card, microSDHC Card, microSDXC Card |
| Included Accessories: | Drill hole template, lens tool, Resistorx L-key, masking kit |
| Compliant Standards: | EN 61000-6-1, EN 61000-6-2, IEC 60068-2-27, FCC Part 15 B Class A, IEC 60068-2-64, IEC 60068-2-1, IEC 60068-2-2, EN 50121-4, IEC 62236-4, VCCI Class A, RCM, EN 50121-3-2, IS13252, IEC 62471, EN 50498, EN 45545-2, KN35, EN 50155, NEMA250 Type 4X, AS/NZS CISPR 32 Class A, EN 55032 Class A, KCC KN32 Class A, IEC/EN/UL 60950-22, ISO 20653, IEEE 802.3af, IEEE 802.3at, IEC 60721-3-5 Class 5M3, CAN/CSA-C22.2 No. 62368-1, EN 55035, IEC/EN/UL 62368-1, IEC/EN 60529 IP66, IEEE 802.1x, IP6K9K, CAN/CSA C22.2 No. 60950-22, NIST SP500-267, EN 50155:2017 Class OT2/ST2, ICES-3(A)/NMB-3(A), UN ECE R118, IEC/EN 61373 Category 1 Class B, IEC/EN 60529 IP67, ECE-R10 Rev.6 (E approval), IEC/EN 62262 IK10+ |
| Power Requirements: | PoE Class 3 |
| Software Included: | Windows decoder 1-user licence |
| Service & Support: | Limited warranty - 5 years |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 55 °C |
| Relative Humidity (operating): | 10 - 95% (non-condensing) |
