| Device Type: | Network surveillance camera |
| Form Factor: | Dome |
| Camera Mount Type: | Wall mount, ceiling mount |
| Connectivity Technology: | Wired |
| Width: | 14.9 cm |
| Depth: | 14.9 cm |
| Height: | 15.6 cm |
| Тегло, kg: | 0.86 |
| Localisation: | United States, United Kingdom, Korea, Japan, India, Europe, China, Brazil, Australia, Argentina |
| Type (Camera): | Colour - Day&Night - fixed - outdoor - vandal / weatherproof |
| Type (Image Sensor): | 5 MP PS RGB CMOS 1/2.8" |
| Type (Lens Construction): | Vari-focal |
| Max Digital Video Resolution: | 2560 x 1440 |
| Motion Detection: | Yes |
| Exposure Range: | 2 sec - 1/30500 sec |
| Infrared LEDs: | Yes |
| Infrared Distance: | 40 m |
| Digital Video Capture Resolution: | 2560 x1440, 1920 x 1200, 2592 x 1944 |
| Frame Rate (max): | 30 frames per second |
| RAM: | 2 GB |
| Flash Memory: | 8 GB |
| Features: | IR Corrected lens, remote zoom, remote focus, Forensic WDR, Lightfinder 2.0 technology, deep learning processing unit (DLPU), Zipstream technology, digital PTZ function, Adaptive Bitrate (ABR), Multi-Bitrate (MBR), Variable Bitrate (VBR), video streaming indicator, 180° image rotation, 270° image rotation, 90° image rotation, brightness control, compression, contrast control, Corridor mode, day/night threshold, defogging, distortion correction function, dynamic text, exposure zone, image mirror, image overlay, Privacy Mask Function, saturation control, sharpness control, white balance, Axis device ID, Axis Edge Vault, brute force delay protection, centralised certificate management, digest authentication, HTTPs encryption, IP address filtering, password protection, secure boot, secure keystore, signed video, VAPIX support, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Pixel Counter Support, human detection, Vehicle Detection, OptimizedIR, memory card encryption, NAS-Ready, up to 7 individually cropped out view areas, -190° / +190° rotation |
| Focal Length: | 3 mm - 8.5 mm |
| Lens Iris: | F/1.38-2.58 auto iris (P-Iris) |
| Min Focus Distance: | 1 m |
| Horizontal Field of View (degree): | 104 - 34 |
| Vertical Field of View (degree): | 76 - 26 |
| Range (degree) (Panning): | -190 to +190 |
| Range (degree) (Tilting): | -50 to +80 |
| Network Interface: | Ethernet 10Base-T/100Base-TX |
| Network Protocols: | IPv4, IPv6, USGv6, ICMP, HTTP, HTTPS, TLS, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, RTSP, RTCP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, DHCP, ARP, SOCKS, SSH, SIP, LLDP, CDP, MQTT, Syslog, Zeroconf |
| Alarm Inputs Qty: | 1 |
| Alarm Outputs Qty: | 1 |
| Supported Memory Cards: | microSD Card, microSDHC Card, microSDXC Card |
| Encryption Algorithm: | TLS 1.2, TLS 1.3 |
| Included Accessories: | Terminal block connectors, cable gaskets, connector guard, weathershield |
| TAA Compliant: | Yes |
| Compliant Standards: | IEEE 802.1x, PVC-free, BFR-free, CFR free, IEEE 802.3af, IEEE 802.3at, EMC, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KN32 Class A, KCC KN35, RCM, AS/NZS CISPR 32 Class A, VCCI Class A, CAN/CSA C22.2 No. 62368-1 ThirdEdition, IEC/EN/UL 62368-1, IEC/EN 62471, IS13252, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA250 Type 4X, NEMA TS-2 (2.2.7-2.2.9), NIST SP500-267, JEDEC, ECA, RoHS, IP66 |
| Colour: | White, NCS S 1002-B |
| Power Requirements: | PoE Plus Class 3 |
| Power Device: | 4.7 Watt |
| Software Included: | AXIS Object Analytics, AXIS Video Motion Detection |
| Service & Support: | Limited warranty - 5 years |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 50 °C |
| Relative Humidity (operating): | 10 - 100% RH (condensing) |
