| Device Type: | Network surveillance camera |
| Audio Support: | Yes: two-way audio capability, 10-band graphic equaliser, speaker pairing, microphone pairing |
| Audio Formats: | LPCM, AAC-LC, G.711, PCM, G.726, ADPCM, OPUS |
| Form Factor: | Bullet |
| Connectivity Technology: | Wired |
| Width: | 18.3 cm |
| Depth: | 46.4 cm |
| Height: | 18.3 cm |
| Тегло, kg: | 3.2 |
| Localisation: | Australia, Argentina, Brazil, China, Europe, Japan, United Kingdom, United States |
| Type (Camera): | Colour - Day&Night - fixed - outdoor - vandal / weatherproof |
| Type (Image Sensor): | PS RGB CMOS 1/2.8" |
| Type (Lens Construction): | Vari-focal |
| Digital Video Format: | H.264B, H.264M, H.264H, H.265, MJPEG |
| Max Digital Video Resolution: | 1920 x 1080 |
| Motion Detection: | Yes |
| Video Modes: | 1080p |
| Exposure Range: | 2 sec - 1/111000 sec |
| Infrared LEDs: | Yes |
| Infrared Distance: | 50 m |
| RAM: | 2 GB |
| Flash Memory: | 8 GB |
| Features: | Licence plate recognition (LPR), remote zoom, remote focus, infrared-cut filter, OptimizedIR, 250km/h max. vehicle speed, deep learning processing unit (DLPU), Zipstream technology, Variable Bitrate (VBR), Adaptive Bitrate (ABR), Multi-Bitrate (MBR), low latency mode, video streaming indicator, Forensic WDR, 2D Noise Reduction Technology, 3D Noise Reduction Technology, Lightfinder 2.0 technology, half duplex audio, spectrum visualizer, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Defog, Pixel Counter Support, level grid, leveling assistant, Audio Detection |
| Optical Zoom: | 20 x |
| Focal Length: | 7 mm - 137 mm |
| Lens Iris: | F/1.5-4.0 auto iris (P-Iris) |
| Min Focus Distance: | 1.2 m |
| Horizontal Field of View (degree): | 2.3 - 38 |
| Vertical Field of View (degree): | 1.3 - 22 |
| Range (degree) (Panning): | -180 to +180 |
| Range (degree) (Tilting): | 0 to -90 |
| Network Interface: | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols: | IPv4, IPv6, USGv6, ICMP, HTTPS, HTTP, HTTP/2, QOS, FTP, SFTP, CIFS, SMB, SMTP, MDNS, Bonjour, UPnP, SNMP, SNMP 2c, SNMP 3, DNS, DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, RTSPS, TCP, UDP, IGMP, IGMPv2, IGMPv3, RTCP, DHCPv4, DHCPv6, SSH, LLDP, CDP, MQTT, Syslog, Zeroconf |
| Supported Memory Cards: | microSD Card, microSDHC Card, microSDXC Card |
| Encryption Algorithm: | TLS 1.2, TLS 1.3 |
| Included Accessories: | Terminal block connector, connector guard, cable gaskets, owner authentication key |
| Cables Included: | 1 x network cable - external |
| TAA Compliant: | Yes |
| Compliant Standards: | UL, cUL, BIS, UKCA, KC, VCCI, RCM, CISPR 35, CISPR 32 Class A, EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, AS/NZS CISPR 32 Class A, ICES-3(A)/NMB-3(A), VCCI Class A, KS C 9835, KS C 9832 Class A, FCC Part 15 B Class A, IEC 62236-4, CAN/CSA C22.2 No. 62368-1 ThirdEdition, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, IK08, NEMA 250 Type 4X, NEMA TS-2 (2.2.7-2.2.9), NIST SP500-267, ETSI EN 303 645, FIPS 140, IEEE 802.1x, IEEE 802.1ae, IEEE 802.1ar, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, PVC-free, BFR-free, CFR free, JS709, RoHS 2011/65/EU Amendment 2015/863, EN/IEC 63000:2018, REACH 2006/1907 |
| Colour: | Grey, NCS S 5502-B, black, NCS S 9000-N |
| Power Requirements: | DC 10 - 28 V / AC 20 - 24 V / PoE class 6 |
| Software Included: | AXIS Object Analytics, AXIS Scene Metadata, AXIS Speed Monitor, AXIS Video Motion Detection |
| Service & Support: | Limited warranty - 5 years |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 60 °C |
| Relative Humidity (operating): | 10 - 85% RH (condensing) |
