| Device Type: | Network surveillance camera |
| Audio Support: | Yes: two-way audio capability |
| Audio Formats: | PCM, G.726, ADPCM, AAC-LC, LPCM, G.711, OPUS |
| Form Factor: | Dome |
| Camera Mount Type: | Wall mount, ceiling mount |
| Connectivity Technology: | Wired |
| Width: | 12.1 cm |
| Depth: | 12.1 cm |
| Height: | 7.1 cm |
| Тегло, kg: | 0.35 |
| Type (Camera): | Colour - Day&Night - fixed |
| Type (Image Sensor): | PS RGB CMOS 1/2.7" |
| Type (Lens Construction): | Vari-focal |
| Digital Video Format: | MPEG-4, MJPEG, H.264, AVC, HEVC, H.265, MPEG-4 Part 10, MPEG-H Part 2 |
| Max Digital Video Resolution: | 2304 x 1728 |
| Motion Detection: | Yes |
| Exposure Range: | 1 sec - 1/37500 sec |
| Digital Video Capture Resolution: | 320 x 240, 2304 x 1728 |
| Frame Rate (max): | 60 frames per second |
| RAM: | 1 GB |
| Flash Memory: | 512 MB |
| Features: | Sharpness control, white balance, colour control, brightness control, contrast control, image mirror, Wide Dynamic Range (WDR), infrared cut filter, Privacy Mask Function, NAS-Ready, tamper-detection, notification picture to E-mail, digital PTZ function, password protection, Variable Bitrate (VBR), Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, image overlay, exposure control, CorridorView, ONVIF (Profile T) support, VAPIX support, Lightfighter technology, motion-adaptive exposure, compression, text overlay, object classification, ONVIF (Profile M) support, AXIS Object Analytics |
| Optical Zoom: | 1.4 x |
| Focal Length: | 3 mm - 6 mm |
| Lens Iris: | F/1.9-2.7 fixed iris |
| Horizontal Field of View (degree): | 45 - 100 |
| Vertical Field of View (degree): | 34 - 72 |
| Range (degree) (Panning): | -180 to +180 |
| Range (degree) (Tilting): | -40 to +65 |
| Network Interface: | Ethernet 10Base-T/100Base-TX |
| Network Protocols: | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, CIFS, SRTP, EAP, SFTP, LLDP, Zeroconf, USGv6, MQTT |
| Supported Memory Cards: | microSD Card, microSDHC Card, microSDXC Card |
| Compliant Standards: | EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, FCC Part 15 B Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, KC, VCCI Class A, RCM, IS13252, KN35, AS/NZS CISPR 32 Class A, KN32 Class A, EN 55032 Class A, IEC/EN 62471, IEEE 802.3af, IEEE 802.3at, EN 55035, IEC/EN/UL 62368-1, IEEE 802.1x, NIST SP500-267, ICES-3(A)/NMB-3(A), IEC/EN 62262 IK10, IEC/EN 60529 IP52 |
| Power Requirements: | PoE Class 2 |
| Power Device: | 2.8 Watt |
| Software Included: | Windows decoder 1-user licence, AXIS Video Motion Detection, AXIS Object Analytics |
| Service & Support: | Limited warranty - 5 years |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 45 °C |
| Relative Humidity (operating): | 10 - 85% RH (non-condensing) |
