| Device Type: | Network surveillance camera |
| Audio Support: | Yes: two-way audio capability |
| Audio Formats: | LPCM, AAC-LC, G.711, PCM, G.726, ADPCM, OPUS |
| Form Factor: | Box |
| Camera Mount Type: | Wall mount |
| Connectivity Technology: | Wired |
| Width: | 15.9 cm |
| Depth: | 40.4 cm |
| Height: | 16.6 cm |
| Тегло, kg: | 2.47 |
| Localisation: | Argentina, Australia, Brazil, China, European Union, India, Japan, United Kingdom, United States |
| Type (Camera): | Colour - Day&Night - fixed - outdoor - vandal / weatherproof |
| Type (Image Sensor): | 5 MP PS RGB CMOS 1/2.7" |
| Type (Lens Construction): | CS-mount - vari-focal |
| Digital Video Format: | H.264, H.265, MJPEG, MPEG-4 Part 10, AVC, MPEG-H Part 2, HEVC |
| Max Digital Video Resolution: | 2592 x 1944 |
| Motion Detection: | Yes |
| Infrared LEDs: | Yes |
| Infrared Distance: | 50 m |
| RAM: | 2 GB |
| Flash Memory: | 8 GB |
| Features: | Axis Edge Vault, IR Corrected lens, infrared-cut filter, Forensic WDR, Lightfinder 2.0 technology, replaceable lens, Electronic Image Stabilizer (EIS), secure boot, deep learning processing unit (DLPU), Zipstream technology, Variable Bitrate (VBR), Adaptive Bitrate (ABR), Multi-Bitrate (MBR), low latency mode, video streaming indicator, 2D Noise Reduction Technology, 3D Noise Reduction Technology, 180° image rotation, 270° image rotation, 90° image rotation, image mirror, text overlay, image overlay, dynamic text, Privacy Mask Function, polygon privacy mask, target aperture, digital PTZ function, control queue, on-screen directional indicator, guard tour, auto gain control, network speaker pairing, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, day/night shift level, Defog, microphone pairing, speaker pairing, Audio Detection, leveling assistant, Remote Back Focus, Axis device ID, secure keystore, signed firmware, signed video, brute force delay protection, digest authentication, IP address filtering, DORI coverage |
| Optical Zoom: | 4.6 x |
| Focal Length: | 2.8 mm - 13 mm |
| Lens Iris: | F/1.4 auto iris (P-Iris) |
| Horizontal Field of View (degree): | 24 - 112 |
| Vertical Field of View (degree): | 18 - 50 |
| Network Interface: | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols: | IPv4, IPv6, USGv6, ICMPv4, ICMPv6, HTTP, HTTPS, HTTP/2, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, RTSPS, TCP, UDP, IGMP, IGMPv2, IGMPv3, RTCP, ICMP, DHCPv4, DHCPv6, ARP, SSH, LLDP, CDP, MQTT, Syslog, Zeroconf, TLS, MDNS |
| Control Interface: | RS-485, RS-422 |
| Alarm Inputs Qty: | 2 |
| Alarm Outputs Qty: | 2 |
| Supported Memory Cards: | microSD Card, microSDHC Card, microSDXC Card |
| Encryption Algorithm: | TLS 1.2, TLS 1.3, FIPS 140 |
| Included Accessories: | Terminal block connectors, wall mount kit, owner authentication key |
| Compliant Standards: | IEEE 802.1ar, UL, cUL, UKCA, KC, EAC, VCCI, RCM, CISPR 35, CISPR 32 Class A, EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-6-1, EN 61000-6-2, VCCI Class A, KS C 9835, KS C 9832 Class A, FCC Part 15 B Class A, CAN/CSA C22.2 No. 62368-1 ThirdEdition, IEC/EN/UL 62368-1 Third Edition, IS 13252, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, NIST SP500-267, ETSI EN 303 645, FIPS 140, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, PVC-free, BFR-free, CFR free, RoHS 2011/65/EU, EN 63000:2018, REACH 2006/1907 |
| Colour: | White, NCS S 1002-B, black |
| Power Requirements: | PoE Class 4 |
| Power Device: | 8.5 Watt |
| Software Included: | AXIS Object Analytics, AXIS Live Privacy Shield, AXIS Video Motion Detection |
| Service & Support: | Limited warranty - 5 years |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 60 °C |
