| Device Type: | Network surveillance camera |
| Audio Support: | Yes: two-way audio via edge-to-edge technology |
| Audio Formats: | PCM, G.726, ADPCM, AAC-LC, LPCM, G.711, OPUS |
| Form Factor: | Dome |
| Camera Mount Type: | Wall mount, ceiling mount |
| Connectivity Technology: | Wired |
| Width: | 14.9 cm |
| Depth: | 14.9 cm |
| Height: | 10.7 cm |
| Тегло, kg: | 0.8 |
| Type (Camera): | Colour - Day&Night - fixed - indoor |
| Type (Image Sensor): | 8 MP PS RGB CMOS 1/1.8" |
| Type (Lens Construction): | Vari-focal |
| Digital Video Format: | MJPEG, H.264, AVC, HEVC, H.265, MPEG-4 Part 10, MPEG-H Part 2 |
| Max Digital Video Resolution: | 3840 x 2160 |
| Motion Detection: | Yes |
| Video Modes: | 4K |
| Exposure Range: | 1/5 sec - 1/8500 sec |
| Infrared LEDs: | Yes |
| Infrared Distance: | 40 m |
| Digital Video Capture Resolution: | 3840 x 2160, 160 x 90 |
| Frame Rate (max): | 30 frames per second |
| RAM: | 2 GB |
| Flash Memory: | 8 GB |
| Features: | Sharpness control, white balance, saturation control, brightness control, contrast control, image mirror, Privacy Mask Function, NAS-Ready, digital PTZ function, password protection, distortion correction function, IR Corrected lens, Variable Bitrate (VBR), OptimizedIR, Zipstream technology, remote focus, ONVIF (Profile S) support, ONVIF (Profile G) support, image overlay, Pixel Counter Support, digest authentication, Vehicle Detection, Forensic WDR, IP address filtering, exposure zone, HTTPs encryption, human detection, simplex audio, signed firmware, secure boot, Corridor mode, ONVIF (Profile T) support, Adaptive Bitrate (ABR), VAPIX support, Lightfinder 2.0 technology, day/night threshold, defogging, compression, 180° image rotation, 90° image rotation, 270° image rotation, memory card encryption, user access log, centralised certificate management, brute force delay protection, ONVIF (Profile M) support, remote zoom, Axis Edge Vault, Multi-Bitrate (MBR), Axis device ID, secure keystore, video streaming indicator, dynamic text, signed video, deep learning processing unit (DLPU), up to 2 view areas |
| Optical Zoom: | 2 x |
| Focal Length: | 4.3 mm - 8.6 mm |
| Lens Iris: | F/1.5 auto iris (P-Iris) |
| Min Focus Distance: | 50 cm |
| Horizontal Field of View (degree): | 53 - 100 |
| Vertical Field of View (degree): | 30 - 54 |
| Range (degree) (Panning): | -190 to +190 |
| Range (degree) (Tilting): | -10 to +80 |
| Network Interface: | Ethernet 10Base-T/100Base-TX |
| Network Protocols: | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, QOS, IGMPv2, IGMPv3, CIFS, SRTP, SFTP, SIP, LLDP, Zeroconf, USGv6, MQTT, CDP, Syslog |
| Supported Memory Cards: | microSD Card, microSDHC Card, microSDXC Card |
| Included Accessories: | Cable gaskets, drill hole template, connector guard, terminal block connectors, RESISTORX T20 screw bit |
| Compliant Standards: | EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EMC, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, FCC Part 15 B Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, EN 50121-4, IEC 62236-4, VCCI Class A, RCM, IS13252, AS/NZS CISPR 32 Class A, KN32 Class A, BFR-free, EN 55032 Class A, IEC/EN 62471, IEEE 802.3af, IEEE 802.3at, KCC KN35, EN 55035, IEC/EN/UL 62368-1, IEEE 802.1x, PVC-free, NIST SP500-267, ICES-3(A)/NMB-3(A), IEC/EN 62262 IK10, IEC/EN 60529 IP52, CAN/CSA C22.2 No. 62368-1 Third Edition, CFR free |
| Colour: | White, NCS S 1002-B |
| Power Requirements: | PoE Plus Class 3 |
| Power Device: | 5.5 Watt |
| Software Included: | Windows decoder 1-user licence, AXIS Video Motion Detection, AXIS Object Analytics |
| Service & Support: | Limited warranty - 5 years |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 50 °C |
| Relative Humidity (operating): | 10 - 85% RH (non-condensing) |
