| Device Type: | Switch - 16 ports - L3 - smart |
| Enclosure Type: | Rack-mountable |
| Subtype: | Gigabit Ethernet |
| Ports: | 16 x 10/100/1000 (PoE+) + 2 x Gigabit Ethernet SFP |
| Power Over Ethernet (PoE): | PoE+ |
| PoE Budget: | 120 W |
| MAC Address Table Size: | 8000 entries |
| Jumbo Frame Support: | 9000 bytes |
| Routing Protocol: | STP, static IP routing, MSTP, RSTP, IGMP, IGMPv2, IGMPv3, CIDR, MLD, MLDv2, Bounjour |
| Remote Management Protocol: | CLI, Telnet, SSH, SSH-2, DHCP, ICMP, SNMP, RADIUS, Syslog, HTTP, HTTPS, SNMP 2c, SNMP 3, RMON, TFTP, SCP |
| Encryption Algorithm: | SSL |
| Authentication Method: | RADIUS |
| Features: | Fanless, QoS, ACL support, eco-friendly button, EEE, PVST+, Link Aggregation, port grouping, LACP support, LAG, VLAN support, Auto Surveillance VLAN, Guest VLAN, port-based VLAN, tag-based VLANs, VLAN management, Voice VLAN, VSDP, Zero-Touch Deployment, GARP, GVRP, IGMP snooping, IGMP querier, loopback detection, UDP, BOOTP support, STP loop guard, SCT, SSD, trustworthy systems, Port Security, BSC, MSC, Storm Control, Unknown Storm Control, DoS attack prevention, TCP/UDP proxy, DSCP based CoS, SP, WRR queuing, ToS, DiffServ support, EQS, ingress rate limiting, TCP congestion, SNTP support, TFTP support, DHCP client, DNS client, SNMP trap, remote firmware upgrade, Cable Diagnostics Function, DHCP server, port mirroring, SCP, VLAN mirroring, Telnet client, cable length detection, chip guard, boot integrity, LLDP, LLDP-MED, CDP, reset button, time-based port operation, IPv4 and IPv6 dual stack, Telnet server, DAD, path MTU discovery, WRR, Unicast Storm Control, DoS protection, HoL Blocking Prevention, DHCP relay, RPVST+, MSTP support, layer 3 routing |
| Compliant Standards (General): | IEEE 802.1x, IEEE 802.3az, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1Q, IEEE 802.1p, IEEE 802.1ab (LLDP), IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3at, IEEE 802.3af |
| Compliant Standards (Miscellaneous): | Plug and Play, RFC768, RFC783, RFC791, RFC792, RFC793, RFC813, RFC826, RFC879, RFC896, RFC854, RFC855, RFC856, RFC858, RFC894, RFC919, RFC920, RFC922, RFC950, RFC951, RFC1042, RFC1071, RFC1123, RFC1141, RFC1155, RFC1157, RFC1213, RFC1215, RFC1286, RFC1350, RFC1442, RFC1451, RFC1493, RFC1533, RFC1541, RFC1542, RFC1573, RFC1624, RFC1643, RFC1700, RFC1757, RFC1867, RFC1907, RFC2011, RFC2012, RFC2013, RFC2030, RFC2131, RFC2132, RFC2233, RFC2576, RFC2616, RFC2618, RFC2665, RFC2666, RFC2674, RFC2737, RFC2819, RFC2863, RFC3164, RFC3176, RFC3411, RFC3412, RFC3413, RFC3414, RFC3415, RFC3416, RFC4330, RFC4443, RFC4291, RFC2460, RFC4861, RFC4862, RFC1981, RFC4007, RFC3484, RFC5214, RFC4293, RFC3595, CSA 22.2, FCC CFR47 Part 15, UL 62368, WEEE |
| Processor: | X ARM: 1.4 GHz |
| RAM: | 1 GB DDR4 SDRAM |
| Flash Memory: | 512 MB |
| Status Indicators: | System, link/activity/speed, PoE |
| Power Device: | Internal power supply |
| Voltage Required: | AC 100-240 V (50 - 60 Hz) |
| Included Accessories: | Pointer card |
| MTBF: | 706,983 hours |
| Width: | 26.8 cm |
| Depth: | 29.7 cm |
| Height: | 4.4 cm |
| Тегло, kg: | 2.38 |
| Min Operating Temperature: | -5 °C |
| Max Operating Temperature: | 50 °C |
| Humidity Range Operating: | 10 - 90% RH (non-condensing) |
| Min Storage Temperature: | -25 °C |
| Max Storage Temperature: | 70 °C |
| Humidity Range Storage: | 10 - 90% RH (non-condensing) |
