| Суич, тип: | Fixed Port |
| Общ брой портове: | 8 |
| Основни портове, тип: | 10/100/1000Base-T |
| Power Over Ethernet (PoE): | 1x PoE input (802.3af) on port 1 or AC power |
| Uplink портове: | - |
| Свободни (10GB) слотове: | - |
| Управление: | Network PnP, Web user interface, Cisco Business mobile app, Cisco Business Dashboard, SNMP, MIBs, RMON, DHCP, CLI and etc. |
| Stackable: | - |
| Fans: | Fanless |
| Захранване: | 100 to 240V 50 to 60 Hz, external |
| Routing: | Layer 3 static routing |
| Памет (Flash, RAM): | 512 MB (Flash), 1 GB DDR4 (DRAM), 1.5 MB (Packet buffer) |
| Капацитет за маршрутизиране/превключване, Gbps: | 16 Gbps |
| Пропускателна способност, Mpps: | 11.90 Mpps |
| MAC адреси: | 8000 addresses |
| VLAN (брой, стандарти): | Support for up to 255 active VLANs simultaneously; Port-based and 802.1Q tag-based VLANs, Management VLAN, Guest VLAN, Auto Surveillance VLAN (ASV), Voice VLAN |
| QoS: | 8 hardware queues; Port based, 802.1p VLAN priority based, IPv4/v6 IP precedence/Type of Service (ToS)/DSCP based, Differentiated Services (DiffServ), classification and re-marking ACLs, trusted QoS |
| L2 мрежови стандарти: | IEEE 802.3, IEEE 802.3u/ab/ad/z/x/af/at; IEEE 802.1D (STP)/1Q/p VLAN/w RSTP/s Multiple STP/X Port Access Authentication; RFC |
| IPv6 functionality: | IPv6 host mode, IPv6 over Ethernet, Dual IPv6/IPv4 stack, IPv6 Neighbor Discovery (ND), IPv6 stateless address auto-configuration, Path MTU discovery, DAD, ICMP v6, IPv6 over IPv4 network with ISATAP |
| Сигурност: | SSL, SSH, IEEE 802.1X (authenticator role): RADIUS authentication, guest VLAN, single/multiple host mode, and single/multiple sessions; STP; SCT; SSD, Trustworthy systems, Port security, Storm control, DoS prevention, ACLs |
| Размери (Ш, Д, В), mm: | 160 x 128 x 30 mm |
| Опция за монтаж: | Desktop |
