| Device Type: | Switch - 8 ports - L3 - Managed |
| Enclosure Type: | Rack-mountable 1U |
| Subtype: | Gigabit Ethernet |
| Ports: | 8 x 10/100/1000 (PoE+) + 2 x 1000Base-T + 2 x 10 Gigabit SFP+ (uplink) |
| Power Over Ethernet (PoE): | PoE+ |
| PoE Budget: | 240 W |
| MAC Address Table Size: | 32000 entries |
| Jumbo Frame Support: | 9198 bytes |
| Routing Protocol: | OSPF, RIP, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, OSPFv3, EIGRP for IPv6, PIM-SSM, policy-based routing (PBR), RIPng, MSTP |
| Remote Management Protocol: | SNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2, CLI, NETCONF, RESTCONF, YANG |
| Encryption Algorithm: | 256-bit AES |
| Features (General): | Fanless, QoS, Rapid PVST+, SRR, PXE support, RSPAN, Energy Efficient Ethernet, MIB, CoS, FNF, 802.1x authentication, DSCP support, MACsec support, SPAN, EEM, PIM, FHS, PVLAN support, CIR, ACL support, Cisco UADP 2.0, built-in ASIC, NetFlow, EEE, Preboot Execution Environment, Cisco StackWise Technology, ZTP, CoPP, MACsec |
| Features (Power): | High Voltage DC (HVDC) |
| Compliant Standards (General): | IEEE 802.3, IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.1ae, IEEE 802.3at, IEEE 802.3af, IEEE 802.3bt |
| Compliant Standards (Miscellaneous): | Plug and Play, EN 61000-3-2, EN 61000-3-3, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35, EN 55035, EN 62368-1, IEC 62368-1, UL 62368-1 |
| RAM: | 4 GB |
| Flash Memory: | 8 GB |
| Built-in Devices: | RFID tag |
| Status Indicators: | Beaconing, status |
| Expansion Slots: | 1 (total) / 1 (free) x SD Memory Card |
| Power Device: | Internal power supply |
| Power Provided: | 315 Watt |
| Voltage Required: | AC 100-277/ DC 120-418 V (50/60 Hz) |
| Software Included: | Cisco IOS XE 17.9 Universal |
| Width: | 26.9 cm |
| Depth: | 24.4 cm |
| Height: | 4.4 cm |
| Тегло, kg: | 2.99 |
| Min Operating Temperature: | -5 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 5 - 90% (non-condensing) |
| Min Storage Temperature: | -40 °C |
| Max Storage Temperature: | 70 °C |
| Humidity Range Storage: | 5 - 90% (non-condensing) |
