| Суич, тип: | Fixed Port |
| Общ брой портове: | 10 |
| Основни портове, тип: | 8 x 10/100/1000 Mbps PoE ports |
| Power Over Ethernet (PoE): | IEEE 802.3af/802.3at, Ports 1~8, PoE Power Budget: 130 W |
| Uplink портове: | 2 x 100/1000 Mbps SFP |
| Свободни (10GB) слотове: | - |
| Управление: | Web-based GUI (Supports IPv4), D-Link Network Assistant (DNA) |
| Stackable: | - |
| Fans: | Smart Fan |
| Захранване: | 100 to 240 V AC, 50 to 60 Hz Internal Power Supply; Max. Power Consumption: 164.6 W (PoE on), 11.7 W (PoE off) |
| Routing: | Layer 2 Only |
| Памет (Flash, RAM): | Flash Memory: 16 MB; Packet Buffer: 4.1 MB |
| Капацитет за маршрутизиране/превключване, Gbps: | 20 Gbps |
| Пропускателна способност, Mpps: | 14.88 Mpps |
| MAC адреси: | 8K Entries |
| VLAN (брой, стандарти): | Port-based/802.1Q tagged/Surveillance/Voice/ Management VLAN, VLAN Group, Supports 32 static VLAN groups, Max. 4094 VIDs, Asymmetric VLAN |
| QoS: | 802.1p Quality of Service, 4 queues per port, Queue handling, Strict, Weighted Round Robin (WRR), Bandwidth control, Port-based (Ingress/Egress, min. granularity 8 Kb/s), DSCP |
| L2 мрежови стандарти: | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af/at/bt, IEEE 802.3az, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p |
| L3 мрежови стандарти: | - |
| IPv6 functionality: | - |
| Сигурност: | Static MAC addresses, Up to 32 entries, Traffic segmentation, Broadcast/Multicast/Unknown Unicast Storm Control, Port security |
| Размери (Ш, Д, В), mm: | 280 x 180 x 44 mm |
| Опция за монтаж: | Desktop |
| Други: | 11-inch desktop (rack mount included), 1U height |
