| Суич, тип: | Fixed Port |
| Общ брой портове: | 26 |
| Основни портове, тип: | 24x10/100/1000Base-T |
| Power Over Ethernet (PoE): | No |
| Uplink портове: | 2xSFP |
| Свободни (10GB) слотове: | No |
| Управление: | Web-based GUI, D-Link Network Assistant Utility, Compact CLI, Telnet Server, TFTP Client, Configurable MDI/MDIX, SNMP v1/v2c/v3, SNMP Trap, Backup/Upgrade firmware, Smart Wizard, Upload/Download Configuration file, RMONv1, Trusted Host, ICMP v6, SNTP |
| Stackable: | No |
| Fans: | Fanless design |
| Захранване: | Internal Universal Power Supply: 100 - 240 VAC, 50/60 Hz |
| Routing: | Layer 3 Lite |
| Памет (Flash, RAM): | - |
| Капацитет за маршрутизиране/превключване, Gbps: | 52 Gbps |
| Пропускателна способност, Mpps: | 38.7 Mpps |
| MAC адреси: | 8000 MAC address table size |
| VLAN (брой, стандарти): | IEEE 802.1Q; VLAN Group: max. 256 static VLAN groups, max. 4094 VIDs; Asymmetric VLAN; Auto Voice VLAN: max. 10 user defined OUI, max. 8 default OUI; Auto Surveillance VLAN |
| QoS: | 802.1p Quality of Service; 8 queues per port; Queue Handling - Strict, Weighted Round Robin (WRR); Bandwidth Control - Port-based (Ingress/Egress, min granularity 10/100/1000 is 16 Kbps); QoS based on: 802.1p Priority Queues, DSCP, ToS, IPv6, TCP/UDP port |
| L2 мрежови стандарти: | IEEE 802.3, IEEE 802.3u, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X |
| L3 мрежови стандарти: | Static Routing - 124/50 IPv4/6 Static Route Entries |
| IPv6 functionality: | IPv6 Traffic Class, IPv6 Neighbor Discovery (ND), IPv6 address, IPv6 RADIUS Server |
| Сигурност: | Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, DHCP Server Screening, IP-MAC-Port Binding (Smart Binding), 802.1X Port-based Access Control, ARP Spoofing Prevention, Traffic Segmentation, SSH v2, SSL, Port Security |
| Размери (Ш, Д, В), mm: | 440 x 140 x 44 |
| Опция за монтаж: | Rackmount |
