| Type (General): | Server |
| Type (Hard Drive): | SSD - 2.5" |
| Type (Storage Controller): | 1 x RAID - OCP |
| Type (Optical Storage): | No optical drive |
| Product Form Factor: | Rack-mountable - 1U |
| Built-in Devices: | Led panel |
| Embedded Security: | Trusted Platform Module (TPM) Security Chip |
| Server Scalability: | 2-way |
| Hot-Swap Bays Qty: | 8 |
| Localisation: | Region: Germany, Switzerland, Austria, France, United Kingdom, Ireland, Scotland |
| CPU: | Intel Xeon Silver 4510 |
| Clock Speed: | 2.4 GHz |
| Max Turbo Speed: | 4.1 GHz |
| Number of Cores: | 12-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 2 |
| CPU Upgradability: | Upgradable |
| Processor Main Features: | Intel Turbo Boost Technology 2, Hyper-Threading Technology |
| Chipset Type: | Intel C741 |
| Installed Size (Cache Memory): | L3 Cache - 30 MB |
| Installed Size (RAM): | 64 GB (installed) / 8 TB (max) |
| Cache Per Processor: | 30 MB |
| Technology: | DDR5 SDRAM - Advanced ECC |
| Effective Memory Speed: | 4400 MHz |
| Rated Memory Speed: | 5600 MHz |
| Form Factor: | DIMM 288-pin |
| Slots (RAM): | 32 (Total) / 30 (empty) |
| Slots (Expansion / Connectivity): | 2 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode) |
| Features (RAM): | HPE SmartMemory, registered |
| Features (Networking): | PXE support, Wake on LAN (WoL) |
| Configuration Features: | 2 x 32 GB |
| Capacity: | 2 x 960 GB |
| Interface Type: | SATA |
| Controller Interface Type: | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
| Storage Controller Name: | HPE MR408i-o Gen11 SPDM |
| Channel Qty: | 8 |
| Buffer Size: | 4 GB |
| Monitor Type: | None. |
| Video Memory: | 16 MB |
| Video Interfaces: | VGA |
| Interface (Bus) Type: | Open Compute Project mezzanine (OCP) 3.0 |
| Ethernet Ports: | 4 x Gigabit Ethernet |
| Ethernet Controller: | Broadcom BCM5719 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol: | SNMP 3, SMASH CLP, IPMI 2.0 |
| Remote Management Controller: | Integrated Lights-Out 6 |
| Included Accessories: | 5 x standard fans |
| Compliant Standards: | ASHRAE Class A3, ASHRAE Class A4, TLS v1.2, AES, FIPS 140-2, IPv6 Ready, PCI DSS, WEEE 2002/95/EC, ACPI 6.4, ErP Lot 9 |
| Manufacturer Selling Program: | HPE Smart Choice |
| Device Type: | Power supply - hot-plug |
| Power Redundancy: | Optional |
| Power Redundancy Scheme: | 1+1 (with optional power supply) |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Voltage Required: | AC 100-240 V |
| Power Provided: | 1000 Watt |
| 80 PLUS Certification: | 80 PLUS Titanium |
| OS Provided: | No operating system |
| Software: | HPE Server UEFI |
| ENERGY STAR Certified: | Yes |
| ENERGY STAR Version: | 3.0 |
| Service & Support: | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| Width: | 43.46 cm |
| Depth: | 75.31 cm |
| Height: | 4.29 cm |
| Тегло, kg: | 14.56 |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 8 - 90% RH (non-condensing) |
