| Type (General): | Server |
| Type (Hard Drive): | No HDD |
| Type (Storage Controller): | 1 |
| Type (Optical Storage): | No optical drive |
| Product Form Factor: | Rack-mountable - 2U |
| Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability: | 2-way |
| Hot-Swap Bays Qty: | 8 |
| Localisation: | Region: Europe |
| CPU: | Intel Xeon Silver 4514Y |
| Clock Speed: | 2 GHz |
| Max Turbo Speed: | 3.4 GHz |
| Number of Cores: | 16-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 2 |
| CPU Upgradability: | Upgradable |
| Chipset Type: | Intel C741 |
| Installed Size (Cache Memory): | L3 Cache - 30 MB |
| Installed Size (RAM): | 128 GB (installed) / 8 TB (max) |
| Cache Per Processor: | 30 MB |
| Technology: | DDR5 SDRAM |
| Effective Memory Speed: | 2800 MHz |
| Rated Memory Speed: | 2800 MHz |
| Form Factor: | DIMM 288-pin |
| Slots: | 32 (Total) / 28 (empty) |
| Features (RAM): | HPE SmartMemory, registered, slots 17 - 32 are available in two-processor configuration only |
| Features (Networking): | PXE support, Wake on LAN (WoL) |
| Configuration Features: | 4 x 32 GB |
| Controller Interface Type: | NVM Express |
| Storage Controller Name: | HPE NS204i-u |
| Monitor Type: | None. |
| Video Memory: | 16 MB |
| Video Interfaces: | VGA |
| Ethernet Ports: | 2 x 10 Gigabit Ethernet |
| Ethernet Controller: | Broadcom BCM57416 |
| Data Link Protocol: | 10 Gigabit Ethernet |
| Remote Management Controller: | Integrated Lights-Out 6 |
| Included Accessories: | 6 high performance fans |
| Compliant Standards: | AES, TLS v1.2, ACPI 6.3, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9, WEEE 2002/95/EC, FIPS 140-2, low halogen, Triple DES, SMBIOS 3.2, Redfish API |
| Manufacturer Selling Program: | HPE Smart Choice |
| Device Type: | Power supply - hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Voltage Required: | AC 100-240 V |
| Power Provided: | 1000 Watt |
| 80 PLUS Certification: | 80 PLUS Titanium |
| OS Provided: | No operating system |
| OS Certified: | Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, Canonical Ubuntu, Oracle Linux, Citrix |
| Software: | HPE Server UEFI |
| ENERGY STAR Certified: | Yes |
| Service & Support: | Limited warranty - parts and labour - 3 years - on-site |
| Width: | 44.8 cm |
| Depth: | 72.7 cm |
| Height: | 8.75 cm |
| Тегло, kg: | 16 |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 8 - 90% RH (non-condensing) |
