| Type (General): | Server |
| Type (Hard Drive): | SSD |
| Type (Storage Controller): | 1 x RAID - OCP |
| Type (Optical Storage): | No optical drive |
| Product Form Factor: | Rack-mountable - 1U |
| Built-in Devices: | Led panel |
| Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability: | 1-way |
| Hot-Swap Bays Qty: | 8 |
| Localisation: | Region: Europe |
| CPU: | Intel Xeon Silver 4514Y |
| Clock Speed: | 2 GHz |
| Max Turbo Speed: | 3.4 GHz |
| Number of Cores: | 16-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| CPU Upgradability: | Upgradable |
| Processor Main Features: | Intel Turbo Boost Technology |
| Chipset Type: | Intel C741 |
| Installed Size (Cache Memory): | L3 Cache - 30 MB |
| Installed Size (RAM): | 64 GB (installed) / 2.04 TB (max) |
| Cache Per Processor: | 30 MB |
| Technology: | DDR5 SDRAM |
| Effective Memory Speed: | 2800 MHz |
| Rated Memory Speed: | 2800 MHz |
| Form Factor: | DIMM 288-pin |
| Slots: | 16 (Total) / 14 (empty) |
| Features (RAM): | Registered, HPE SmartMemory, 8-channel memory architecture |
| Features (Networking): | ACPI support, PXE support, Wake on LAN (WoL) |
| Configuration Features: | 2 x 32 GB |
| Capacity: | 2 x 480 GB |
| Interface Type: | SATA |
| Controller Interface Type: | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
| Storage Controller Name: | HPE MR408i-o Gen11 SPDM |
| Channel Qty: | 8 |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, RAID 60 |
| Buffer Size: | 4 GB |
| Monitor Type: | None. |
| Video Memory: | 16 MB |
| Video Interfaces: | VGA |
| Ethernet Ports: | 2 x Gigabit Ethernet |
| Ethernet Controller: | Broadcom BCM5720 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol: | IPMI 2.0, SNMP 3 |
| Remote Management Controller: | Integrated Lights-Out 6 |
| Bays: | 8 (total) / 6 (free) x hot-swap 2.5" SFF |
| Included Accessories: | 7 x standard fans |
| Compliant Standards: | AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.3 |
| Manufacturer Selling Program: | HPE Smart Choice |
| Device Type: | Power supply - hot-plug |
| Power Redundancy: | Optional |
| Power Redundancy Scheme: | 1+1 (with optional power supply) |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Power Provided: | 1000 Watt |
| 80 PLUS Certification: | 80 PLUS Titanium |
| OS Provided: | No operating system |
| OS Certified: | Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware ESXi 7.0 update 3, VMware ESXi 8.0, VMware ESXi 8.0 update 1, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP4, Ubuntu 22.04 LTS, CentOS |
| ENERGY STAR Certified: | Yes |
| ENERGY STAR Version: | 4.0 |
| Service & Support: | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| Width: | 43.46 cm |
| Depth: | 60.51 cm |
| Height: | 4.28 cm |
| Тегло, kg: | 12 |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 8 - 90% RH (non-condensing) |
