| Type (General): | Server |
| Type (Hard Drive): | SSD |
| Type (Storage Controller): | 1 x RAID - OCP |
| Type (Optical Storage): | No optical drive |
| Product Form Factor: | Rack-mountable - 1U |
| Built-in Devices: | Led panel |
| Embedded Security: | Trusted Platform Module (TPM) Security Chip |
| Server Scalability: | 1-way |
| Hot-Swap Bays Qty: | 8 |
| Localisation: | Region: Europe, Middle East, Africa |
| CPU: | AMD EPYC 9115 |
| Clock Speed: | 2.6 GHz |
| Max Turbo Speed: | 4.1 GHz |
| Number of Cores: | 16-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| CPU Upgradability: | Upgradable |
| Processor Main Features: | 125W TDP |
| Installed Size (Cache Memory): | L3 Cache - 64 MB |
| Installed Size (RAM): | 64 GB (installed) / 3 TB (max) |
| Cache Per Processor: | 64 MB |
| Technology: | DDR5 SDRAM |
| Effective Memory Speed: | 3000 MHz |
| Rated Memory Speed: | 3200 MHz |
| Form Factor: | DIMM 288-pin |
| Slots: | 12 (Total) / 10 (empty) |
| Features (RAM): | Registered, HPE SmartMemory |
| Features (Hard Drive): | Read Intensive, HPE Multi Vendor |
| Features (Networking): | PXE support, Wake on LAN (WoL) |
| Configuration Features: | 2 x 32 GB |
| Capacity: | 2 x 480 GB |
| Interface Type: | SATA 6Gb/s |
| Controller Interface Type: | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
| Storage Controller Name: | HPE MR408i-o Gen11 SPDM |
| Channel Qty: | 8 |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Buffer Size: | 4 GB |
| Monitor Type: | None. |
| Video Memory: | 16 MB |
| Video Interfaces: | VGA |
| Interface (Bus) Type: | Open Compute Project mezzanine (OCP) 3.0 |
| Ethernet Ports: | 4 x Gigabit Ethernet |
| Ethernet Controller: | Broadcom BCM5719 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol: | IPMI 2.0, SNMP 3 |
| Remote Management Controller: | Integrated Lights-Out 6 |
| Bays: | 8 (total) / 6 (free) x hot-swap 2.5" SFF |
| Included Accessories: | 7 x standard fans, HPE Easy Install Rail 2 Kit, CPU standard heatsink |
| Compliant Standards: | AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1, SMBIOS 3.1, Redfish API, ErP Lot 9, UEFI 2.7, UEFI Class 3, Active Directory v1.0, APML 1.0 |
| Manufacturer Selling Program: | HPE Smart Choice |
| Device Type: | Power supply - hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Power Provided: | 1000 Watt |
| 80 PLUS Certification: | 80 PLUS Titanium |
| OS Certified: | CentOS, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, SuSE Linux Enterprise Server 12 SP3, Red Hat Enterprise Linux 7.4, Red Hat Enterprise Linux 7.5, VMware vSphere 6.5 (ESXi) Update 2, VMware vSphere 6.7 (ESXi) |
| Software: | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
| ENERGY STAR Certified: | Yes |
| ENERGY STAR Version: | 4.0 |
| Service & Support: | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| Width: | 43.46 cm |
| Depth: | 64.94 cm |
| Height: | 4.29 cm |
| Тегло, kg: | 12.56 |
| Shipping Width: | 60 cm |
| Shipping Depth: | 91.6 cm |
| Shipping Height: | 24.2 cm |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 8 - 90% RH (non-condensing) |
