| Type (General): | Server |
| Type (Hard Drive): | SSD |
| Type (Storage Controller): | 1 x RAID - OCP |
| Type (Optical Storage): | No optical drive |
| Product Form Factor: | Rack-mountable - 2U |
| Built-in Devices: | Led panel |
| Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability: | 2-way |
| Hot-Swap Bays Qty: | 8 |
| Localisation: | Region: Europe, Middle East, Africa |
| CPU: | Intel Xeon Silver 4510 |
| Clock Speed: | 2.4 GHz |
| Max Turbo Speed: | 4.1 GHz |
| Number of Cores: | 12-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 2 |
| CPU Upgradability: | Upgradable |
| Processor Main Features: | Intel Turbo Boost Technology 2, Hyper-Threading Technology |
| Chipset Type: | Intel C741 |
| Installed Size (Cache Memory): | L3 Cache - 30 MB |
| Installed Size (RAM): | 64 GB (installed) / 8 TB (max) |
| Cache Per Processor: | 30 MB |
| Technology: | DDR5 SDRAM |
| Effective Memory Speed: | 2200 MHz |
| Rated Memory Speed: | 2800 MHz |
| Form Factor: | DIMM 288-pin |
| Slots: | 32 (Total) / 30 (empty) |
| Features (RAM): | HPE SmartMemory, registered, slots 17 - 32 are available in two-processor configuration only |
| Features (Hard Drive): | Read Intensive, HPE Multi Vendor |
| Features (Networking): | Wake on LAN (WoL), PXE support |
| Configuration Features: | 2 x 32 GB |
| Capacity: | 2 x 480 GB |
| Interface Type: | SATA 6Gb/s |
| Controller Interface Type: | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
| Storage Controller Name: | HPE MR408i-o Gen11 SPDM |
| Channel Qty: | 8 |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Buffer Size: | 4 GB |
| Monitor Type: | None. |
| Video Memory: | 16 MB |
| Video Interfaces: | VGA |
| Interface (Bus) Type: | Open Compute Project mezzanine (OCP) 3.0 |
| Ethernet Ports: | 4 x Gigabit Ethernet |
| Ethernet Controller: | Broadcom BCM5719 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol: | SNMP 3, IPMI 2.0, SMASH CLP |
| Remote Management Controller: | Integrated Lights-Out 6 |
| Compliant Standards (Networking): | OCP 3.0 |
| Compliant Standards (Miscellaneous): | AES, ACPI 6.3, TLS v1.2, ASHRAE Class A3, ASHRAE Class A4, Active Directory v1.0, WEEE 2002/95/EC, FIPS 140-2, SMBIOS 3.2, Redfish API, Triple DES, UEFI 2.7 |
| Bays: | 8 (total) / 6 (free) x hot-swap 2.5" SFF |
| Included Accessories: | 4 standard fans, HPE Easy Install Rail 3 Kit |
| Manufacturer Selling Program: | HPE Smart Choice |
| Device Type: | Power supply - hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Power Provided: | 1000 Watt |
| 80 PLUS Certification: | 80 PLUS Titanium |
| OS Provided: | No operating system |
| OS Certified: | Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware ESXi 7.0 update 3, VMware ESXi 8.0, VMware ESXi 8.0 update 1, VMware ESXi 8.0 update 2, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP4, SUSE Linux Enterprise Micro 5.3, Canonical Ubuntu 20.04.5 LTS, Canonical Ubuntu 22.04 LTS, Oracle Linux 9 |
| Software: | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
| ENERGY STAR Certified: | Yes |
| ENERGY STAR Version: | 3.0 |
| Service & Support: | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| Width: | 44.8 cm |
| Depth: | 72.7 cm |
| Height: | 8.75 cm |
| Тегло, kg: | 16 |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 8 - 90% RH (non-condensing) |
