| Type (General): | Server |
| Type (Hard Drive): | No HDD |
| Type (Storage Controller): | 1 x RAID - OCP 3.0 |
| Type (Optical Storage): | No optical drive |
| Product Form Factor: | Rack-mountable - 1U |
| Built-in Devices: | Led panel |
| Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability: | 2-way |
| Hot-Swap Bays Qty: | 8 |
| Localisation: | Region: Europe |
| CPU: | Intel Xeon 6505P |
| Clock Speed: | 2.2 GHz |
| Max Turbo Speed: | 4.1 GHz |
| Number of Cores: | 12-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 2 |
| CPU Upgradability: | Upgradable |
| Processor Main Features: | Intel Turbo Boost Technology 2, Hyper-Threading Technology, 24 Threads, 150W TDP |
| Installed Size (Cache Memory): | L3 Cache - 48 MB |
| Installed Size (RAM): | 64 GB (installed) / 8 TB (max) |
| Cache Per Processor: | 48 MB |
| Technology: | DDR5 SDRAM - Advanced ECC |
| Effective Memory Speed: | 6400 MT/s |
| Rated Memory Speed: | 6400 MT/s |
| Form Factor: | DIMM 288-pin |
| Slots: | 32 (Total) / 30 (empty) |
| Features: | Registered, slots 17 - 32 are available in two-processor configuration only, HPE SmartMemory |
| Configuration Features: | 2 x 32 GB |
| Storage Controller Name: | HPE MR408i-o Gen11 SPDM |
| Channel Qty: | 8 |
| Buffer Size: | 4 GB |
| Monitor Type: | None. |
| Video Memory: | 16 MB |
| Video Interfaces: | VGA |
| Ethernet Controller: | Broadcom BCM57416 |
| Bays: | 8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Included Accessories: | 5 x standard fans |
| Compliant Standards: | ACPI 6.5, PCIe 5.0, UEFI, SMBIOS 3.7, UEFI 2.10, UEFI Class 3, Redfish API, AES, TLS v1.2, DMTF, Active Directory v1.0, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9, WEEE 2002/95/EC, IPv6 Ready |
| Device Type: | Power supply - hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Voltage Required: | AC 100-240 V |
| Power Provided: | 1000 watt |
| 80 PLUS Certification: | 80 PLUS Titanium |
| OS Provided: | No operating system |
| Software: | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE OneView Advanced |
| EPEAT Compliant: | EPEAT Silver |
| ENERGY STAR Certified: | Yes |
| ENERGY STAR Version: | 4.0 |
| Service & Support: | Limited warranty - parts and labour - 3 years - on-site |
| Width: | 75.31 cm |
| Depth: | 43.46 cm |
| Height: | 4.29 cm |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 8 - 90% RH (non-condensing) |
