| Device Type: | Wireless router |
| Enclosure Type: | Desktop, DIN rail mountable |
| Connectivity Technology: | Wired, wireless |
| Data Link Protocol: | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Ethernet, Fast Ethernet |
| Frequency Band: | 2.4 GHz |
| Network / Transport Protocol: | TCP/IP, UDP/IP, IPv4, IPv6, NTP, DNS, HTTP, HTTPs, FTP, SMTP, ARP, PPPoE, DHCP, Telnet, DDNS, OpenVPN, L2TP, PPTP, WireGuard |
| Routing Protocol: | BGP, OSPFv2, RIP-2, RIP-1, RIPng, OSPF for IPv6, VRRP |
| Remote Management Protocol: | ICMP, SSH, SNMP, MQTT, TR-069, SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS, JSON, Modbus |
| Encryption Algorithm: | WPA2-Enterprise, PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK, AES-CCMP, TKIP, SSL 3.0, TLS, DES, RC2, Blowfish, CAST5, 128-bit AES, 256-bit AES, 192-bit AES, IKEv1, IKEv2, 3DES, MODBUS |
| Authentication Method: | RADIUS, X.509 certificates |
| Features: | SMS alert, white list, black list, band management, auto APN, bridge mode, software access point, client separation, Auto Cipher modes, Stealth Mode, MACsec, Captive Portal, auto-uplink (auto MDI/MDI-X), PPP, Telnet client, WOL, VoIP passthrough support, connection monitoring, DHCP relay, QoS, load balancing, PSK, digital certificates, DDoS Protection, VLAN support, mobile quota control, MAC address filtering, GRE tunneling, FOTA, Teltonika RMS, reset key, aluminium housing, WAN failover |
| Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, UPnP, IP30, RED, UKCA, EN 301 489-1 V2.2.3, EN 301 489-17 V3.2.4 (2020-09), EN 301 489-52 V1.2.0, EN 55032:2015+A1:2020, EN 55035:2017+A11:2020, EN 61000-3-3:2013+A1:2019, EN IEC 61000-3-2:2019, EN 61000-4-2:2009, EN 61000-4-3:2020, EN 61000-4-4:2012, EN 61000-4-5:2014+A1:2017, EN 61000-4-6:2014, EN IEC 61000-4-11:2020, EN 300 328 V2.2.2, EN 301 511 V12.5.1, EN 301 908-1 V13.1.1, EN 301 908-2 V13.1.1, EN 301 908-13 V13.1.1, EN IEC 62311:2020, EN 50665:2017, EN IEC 62368-1:2020+A11:2020, IEC 62368-1:2018 |
| Processor: | 1 x MediaTek MIPS 24KC 580 MHz |
| RAM: | 128 MB |
| Flash Memory: | 16 MB |
| Status Indicators: | Power, status, signal strength |
| Type: | Wireless cellular modem |
| Mobile Communication Protocol: | FDD LTE |
| Generation: | 2G, 3G, 4G |
| Cellular Band: | LTE B1, LTE B20, LTE B28A, LTE B3, LTE B7, LTE B8 |
| Max Transfer Rate: | 150 Mbps |
| VoIP Protocols: | SIP, H.323 |
| Internet of Things (IoT) Compatible: | Yes |
| Platform: | Clouds of Things, ThingWorx, Cumulocity, Azure |
| Expansion Slots: | 1 (total) / 1 (free) x Mini-SIM |
| Aerial: | External detachable |
| Antenna Qty: | 3 |
| Power Device: | External power adapter |
| Voltage Required: | DC 9 - 30 V |
| Electric Current Required: | 1 A |
| Power Consumption Operational: | 6.5 Watt |
| Included Accessories: | SIM card adapter kit, WiFi aerial, 2 x LTE aerials |
| Cables Included: | 1 x network cable - 1.5 m |
| Localisation: | Europe |
| OS Provided: | RutOS |
| Software Included: | ZeroTier VPN |
| Width: | 8.3 cm |
| Depth: | 7.4 cm |
| Height: | 2.5 cm |
| Тегло, kg: | 0.125 |
| Shipping Width: | 17.3 cm |
| Shipping Depth: | 14.8 cm |
| Shipping Height: | 7.1 cm |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 75 °C |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
