| Device Type: | Gateway |
| Width: | 7 cm |
| Depth: | 1.8 cm |
| Height: | 6 cm |
| Тегло, kg: | 0.13 |
| Processors Installed: | 1 x ARM Cortex-A7 1.2 GHz |
| Max Supported Qty: | 1 |
| RAM: | 128 MB |
| Flash Memory: | 512 MB |
| Form Factor: | External |
| Connectivity Technology: | Wired |
| Network / Transport Protocol: | TCP/IP, UDP/IP, NTP, ICMP/IP, DHCP, DNS, DDNS, IPv4, IPv6 |
| Routing Protocol: | GRE |
| Remote Management Protocol: | SNMP, HTTP, HTTPS, SSH, SSH-2, CLI, Modbus, MQTT |
| Capacity: | VPN tunnels: 5 |
| Status Indicators: | Power, status, connection status |
| Features: | Firewall protection, NAT support, interrupt status port (ISP), firmware upgradable, port forwarding, GRE tunneling, static routing, Teltonika Remote Management System (RMS) |
| Encryption Algorithm: | DES, Triple DES, RC2, CAST5, IKE, SSL, TLS, 128-bit AES, 192-bit AES, 256-bit AES, IKEv2 |
| Mobile Broadband Access: | Yes |
| Mobile Communication Protocol: | LTE |
| Expansion Slots: | 1 (total) / 1 (free) x SIM card |
| Compliant Standards: | RoHS, WEEE, X.509, IP30, EAC, EN 61000-4-2:2009, EN 61000-4-11:2004, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-6:2014, EN 61000-4-5:2014, ETSI EN 301-489-1 V2.2.0, RED, IEC 62368-1: 2014 Second Edition, EN 62368-1:2014+A11:2017, ETSI EN 301 908-1 V11.1.1, ETSI EN 301 489-52 V1.1.0, EN 301 489-19 V2.1.0, EN 61000-4-4:2012, EN 300-511 V12.5.1, ETSI EN 301 908-2 V11.1.2, ETSI EN 301 908-13 V11.1.2, EN 50385:2017, EN 62232:2017 |
| Voltage Required: | DC 9 - 30 V |
| Power Consumption Operational: | 5 Watt |
| OS Provided: | RutOS |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 75 °C |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
