| Product Type: | LED-backlit LCD flat panel display |
| Power Consumption (Max): | 484 Watt |
| Power Consumption Operational: | 340 Watt |
| Diagonal Class: | 85" |
| Diagonal Size: | 84.5" |
| Commercial Use: | Yes - spatial signage |
| Series: | SMHX Series |
| 3D: | Yes |
| 3D Technology: | Glasses-free |
| Platform (General): | Tizen OS |
| Platform (Internet of Things (IoT)): | SmartThings Pro |
| Operating System: | Tizen OS 7.0 |
| Video Processor: | Quantum 4K |
| TV Tuner: | No tuner |
| TV Tuner Presence: | No |
| Sensors: | Ambient light sensor (ALS), temperature sensor |
| Video Interface: | HDMI |
| HDMI Ports Qty: | 3 ports |
| PC Interface: | DisplayPort |
| Modes: | Portrait mode |
| Picture Enhancements: | 72% Colour Gamut NTSC, Intelligent UHD upscaling, Mega Dynamic Contrast Ratio |
| Design: | UltraThin |
| Dimensions: | Without stand |
| Width: | 110.12 cm |
| Depth: | 5.2 cm |
| Height: | 192.02 cm |
| Тегло, kg: | 49 |
| Enclosure Colour: | Black |
| LCD Display Technology: | VA |
| Pixel Pitch: | 0.487 mm |
| Resolution: | 3840 x 2160 |
| Display Format: | 4K UHD (2160p) |
| Image Aspect Ratio: | 9:16 |
| LCD Backlight Technology: | LED backlight |
| Coating: | Anti-glare, 25% Glass Haze |
| Image Contrast Ratio: | 4000:1 |
| Brightness: | 500 cd/m² |
| Viewing Angle: | 178 degrees |
| Viewing Angle (Vertical): | 178 degrees |
| Response Time: | 10 ms |
| Commercial Features: | SMART Signage Platform, Samsung VXT CMS, MagicInfo S10 Player, Signage New Home, Microsoft 365, Custom Home, Auto Source Switching & Recovery, upgradable web-engine, Tizen Enterprise Platform, HDR support, AI Studio |
| Operation Hours / Days: | 24 / 7 |
| Features: | SSSP 10.0, Center IR, Workspace, True 3D Enhancer, 3D plate technology, Virtual 3D display, Virtual 3D Spatial Effect |
| Flat Panel Mount Interface: | 400 x 600 mm |
| VESA Compatibility: | Yes |
| USB Port: | Yes |
| USB Ports Qty: | 2 |
| Configuration: | ARM Cortex-A73 Quad-Core ( 1.6 GHz ) 16 GB (available 10 GB) |
| Type: | Remote control |
| Battery Included: | Yes |
| Speaker System: | 2 channel |
| Output Power / Total: | 10 Watt |
| Connectivity: | Wi-Fi, LAN, Bluetooth |
| LAN Protocol: | Ethernet |
| Encryption: | EAP-PEAP, EAP-TLS, EAP-TTLS, WPA2-Enterprise, WPA3-Personal |
| Internet of Things (IoT) Compatible: | Yes |
| Cables Included: | RS-232C (IN) adapter |
| Compliant Standards: | EMC Class A, Safety 60950-1, Safety 62368-1, IP5X |
| Power Device: | Power supply |
| Input Voltage: | AC 100-240 V (50/60 Hz) |
| Power Consumption Sleep: | 0.5 Watt |
| Width (Shipping): | 209.3 cm |
| Depth (Shipping): | 22 cm |
| Height (Shipping): | 123.4 cm |
| Weight (Shipping): | 61.9 kg |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 10 - 80% |
