| Product Type: | Door controller |
| Functions: | Tamper detection |
| Power Source: | PoE |
| Placing / Mounting: | DIN rail-mounting, wall console mounting |
| Connectivity Technology: | Wired - Ethernet, Fast Ethernet, Wiegand, RS-485 |
| Features: | 1-2 doors support, PoE+, barebone, password protection, IP address filtering, HTTPS encryption, digest authentication, user access log, centralised certificate management, brute force delay protection, signed firmware, secure boot, Axis Edge Vault, secure keystore, IPv4 support, IPv6 support, Internet Control Message Protocol (ICMP), HTTP support, Quality of Service (QoS), DiffServ support, SFTP support, mDNS, SNMP support, DNS support, DDNS (Dynamic Domain Name Service), NTP support, NTS support, RTSP support, RTCP support, RTP support, SRTP support, TCP support, UDP support, IGMP support, DHCP support, ARP support, NTCIP support, SIP support, LLDP support, CDP support, MQTT support, Syslog support, ZeroConf support |
| Installed Size (RAM): | 512 MB |
| Installed Size (Flash Memory): | 2 GB |
| Colour: | White, NCS S 1002-B |
| Encryption Algorithm: | EAP-TLS, TLS |
| Authentication Method: | Secure Shell (SSH) |
| Warranty: | 5-year warranty |
| Compliant Standards: | IEEE 802.3at, UL 2043, UL 294, IEEE 802.1x, EAL 6+, USGv6, PVC-free, EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, AS/NZS CISPR 32 Class A, RCM, KS C 9832 Class A, KS C 9835, IEC/EN/UL 62368-1, CAN/CSA-C22.2 No. 62368-1, EN 50581 |
| Width: | 17.5 cm |
| Depth: | 17.5 cm |
| Height: | 5 cm |
| Тегло, kg: | 0.8 |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 70 °C |
| Designed For: | AXIS A4020-E Reader, A4120-E, A9161 Network I/O Relay Module, A9188 Network I/O Relay Module, A9188-VE Network I/O Relay Module |
